Automatic Paste Filling Machine

APF - 1825 is an innovative advanced technology designed to deliver uniform wet paste filling around the tubular grids inside the gauntlets. It is also designed to increase the contact between the lead oxide paste and the spine, which greatly improves the battery life and performance.

APF - 1825 is employed to fill the tubular grids with lead oxide and it consist of the below process components:

Functionality

The lead oxide paste from the mixer is poured into the Hopper. The stirrer inside the Hopper maintains uniform feeding of the paste at all time of the operation.

The tubular gauntlets with the lead grid is placed on the delivery rack and the Controlled Oxide Paste Injector (COPI) automatically delivers precise amount of oxide paste into the tubular sleeves uniformly and compactly. The entire process enables the compact contact between the oxide paste and the spines inside the gauntlet. The paste filling from APF - 1825 is so precise to your requirement, that the tubular grid maintain uniform weight throughout the production process. The Automated Control System helps in fast production and maintains quality at par.

APF - 1825 Advantages

• Precise and compact filling of Lead Oxide Paste in the Tubular Grid
• High contact between Oxide paste and spine
• Oxide wastage is negligible compared to powder filling
• No Pickling Process Required Saves production time
• Fast, accurate and consistent production cycle
• Extended Battery life due to compact paste filling

Technology Advantages

• One-man operation per machine
• Rigid body, latest technology, long lasting components
• Safety and environment compliant
• Industry best power consumption by usage of current sensing electronics
• Designed to facilitate quick installation

Advanced Features

• Flexible adjustments in the settings to accommodate a wide variety of Lead Oxide paste formulas
• Non-stop high quality production capabilities
• Oxide Valve Control mechanism - Uniform density of the paste across the tubular grid
• Capable of pasting Lead Alloy with high and low Antimony with Calcium
• Elimination of Negative Electrode contamination when using High Antimony combination
• Advanced Controlled Oxide Paste Injector System Precise filling with weight tolerance in the range of 0.5% to 2%
• Higher performance with Non Woven Gauntlets and Woven gauntlets
• Worry free, maintenance free duty cycle within first 3 years
• APF 1825 Accommodates Standard Plate lengths from 110mm to 600mm ( customizable as per customer requirement)
• Changing plates lengths at ease just change the dye 20 Minutes
